Description
Parameters
| Features | Application |
| With DDM?function. | Gigabit Ethernet. |
| Low power dissipation. | Fiber Channel. |
| Commercial Temperature Range: 0~+70℃. | Switch to Switch Interface. |
| Hot-Pluggable SFP Footprint. | Other Optical Links |
3Gb/s SFP?BIDI Single Mode Optical Transceiver
Model | Rate | Wavelength | Transmission Distance | Output Opt. Pwr. | Rx. Sensitivity | Laser | Interface |
FYSFB-3530-02B | 3Gb/s | Tx1310/Rx1550nm | 2KM | -9~-3dBm | ≤-18dBm | DFB | LC/SC |
FYSFB-5330-02B | 3Gb/s | Tx1550/Rx1310nm | 2KM | -9~-3dBm | ≤-18dBm | DFB | LC/SC |
FYSFB-3530-10B | 3Gb/s | Tx1310/Rx1550nm | 10KM | -5~0dBm | ≤-20dBm | DFB | LC/SC |
FYSFB-5330-10B | 3Gb/s | Tx1550/Rx1310nm | 10KM | -5~0dBm | ≤-20dBm | DFB | LC/SC |
FYSFB-3530-40B | 3Gb/s | Tx1310/Rx1550nm | 40KM | 0~3dBm | ≤-22dBm | DFB | LC/SC |
FYSFB-5330-40B | 3Gb/s | Tx1550/Rx1310nm | 40KM | 0~3dBm | ≤-22dBm | DFB | LC/SC |
Flyin's 3G SFP transceiver module is individually tested to be used on a series of switches, routers, servers, network interface card etc. Featuring low power consumption, high speed, this easy to install.
| Features | Application |
| With DDM?function. | Gigabit Ethernet. |
| Low power dissipation. | Fiber Channel. |
| Commercial Temperature Range: 0~+70℃. | Switch to Switch Interface. |
| Hot-Pluggable SFP Footprint. | Other Optical Links |
3Gb/s SFP?BIDI Single Mode Optical Transceiver
Model | Rate | Wavelength | Transmission Distance | Output Opt. Pwr. | Rx. Sensitivity | Laser | Interface |
FYSFB-3530-02B | 3Gb/s | Tx1310/Rx1550nm | 2KM | -9~-3dBm | ≤-18dBm | DFB | LC/SC |
FYSFB-5330-02B | 3Gb/s | Tx1550/Rx1310nm | 2KM | -9~-3dBm | ≤-18dBm | DFB | LC/SC |
FYSFB-3530-10B | 3Gb/s | Tx1310/Rx1550nm | 10KM | -5~0dBm | ≤-20dBm | DFB | LC/SC |
FYSFB-5330-10B | 3Gb/s | Tx1550/Rx1310nm | 10KM | -5~0dBm | ≤-20dBm | DFB | LC/SC |
FYSFB-3530-40B | 3Gb/s | Tx1310/Rx1550nm | 40KM | 0~3dBm | ≤-22dBm | DFB | LC/SC |
FYSFB-5330-40B | 3Gb/s | Tx1550/Rx1310nm | 40KM | 0~3dBm | ≤-22dBm | DFB | LC/SC |
