工作波長/Operating Wavelength

1260 ~ 1620

nm

中心波長(λc)/Center Wavelength(λc)

1471

nm

透射通道帶寬/Channel Pass Bandwidth? ?

1404.5~1417.5

nm

透射通道插入損耗/Pass ? Channel Insertion Loss (Com-T)

≤1.0

dB

反射通道插入損耗/Reflect Channel Insertion Loss（Com-Reflect）

≤0.8

dB

平坦度/Ripple

≤0.3

dB

透射通道隔離/Pass Channel Isolation

≥30

dB

反射通道隔離/Reflect Channel Isolation

≥12

dB

方向性/Directivity

≥40

dB

回波損耗/Return Loss

≥45

dB

熱穩(wěn)定性/Thermal Stability

≤0.005

dB/℃

熱溫漂/Thermal Stability Drift

≤5

pm/℃

偏振相關(guān)損耗/Polarization Dependent Loss

≤0.10

dB

偏振模色散/Polarization Mode Dispersion

≤0.10

ps

最大光功率/Maximum Power Handing

300

mW

光纖長度/Fiber Length

≥2

m

光纖類型/Fiber Type

2.0mm LSZH SM

工作溫度/Operating Temperature

0 ~ 70

℃

儲存溫度/Storage Temperature

-40 ~ 85

℃

拉伸載荷/Tensile load

5

N
